5.2
Mounting the product
Install the product upstream of the burner. The fitting can be installed above
or below the maximum tank level.
Verify that the permissible ambient temperature is not exceeded.
Verify that the product is not mounted the product on top of or next to a
non-insulated boiler part, above opening dampers at furnaces or to the
flue gas pipe.
Verify that the float housing points vertically to the top.
LEAKING PRODUCT
•
Verify that you use a screwed pipe connection as per DIN 3852 with cylindri-
cal thread (G thread) and seal the screwed pipe connection with a flat gasket
or with suitable glue. Do nut use Teflon tape or hemp.
Failure to follow these instructions can result in equipment damage.
Mounting
NOTICE
1. Mount the product using
the enclosed bracket and
three self-tapping screws.
2. Use the bracket as a tem-
plate when screwing in the
self-tapping screws.
Fuel oil filters
EN
11
