ATTACHING THE BAR AND
CHAIN (if not already attached)
WARNING:
Recheck each assem-
bly step if the saw is received assembled. Al-
ways wear gloves when handling the chain.
The chain is sharp and can cut you even
when it is not moving!
1. Move ON/STOP switch to the STOP po-
sition.
2. Loosen and remove bar knob completely
by lifting lever and turning counterclock-
wise.
3. Remove clutch cover and plastic ship-
ping spacer (if present).
Clutch Cover
Bar
Knob
4. Slide guide bar on bar bolts until guide
bar stops against clutch drum sprocket.
Clutch retainer/
sprocket
Bar bolts
5. Carefully remove the chain from the pack-
age. Hold chain with the drive links as
shown.
ASSEMBLY
Lever
6. Place chain over and behind clutch re-
7. Fit bottom of drive links between the
LOOSEN
8. Fit chain drive links into bar groove.
9. Pull guide bar forward until chain is snug
10. Install clutch cover making sure the ad-
Location of
shipping
spacer
Adjusting pin
CAUTION:
ling the clutch cover that the adjusting pin
aligns into the lower hole in the guide bar.
Failure to install the clutch cover correctly may
result in permanent damage to your chain saw.
Clutch
Cover
Guide bar
Adjusting Pin
11. Install bar knob. Once the chain is ten-
8
CUTTERS MUST FACE IN
DIIRECTION OF ROTATION
Depth Gauge
Cutters
Drive Links
tainer, fitting the drive links in the clutch
drum sprocket.
teeth in the sprocket in the nose of the
guide bar.
in guide bar groove. Ensure all drive links
are in the bar groove.
justing pin is positioned in the lower hole
in the guide bar. This pin moves the bar
forward (tightening the chain) and back-
ward (loosening the chain) as the outer
tensioning ring is turned.
It is very important when instal-
Lower
Hole
Guide Bar
sioned, you will need to tighten bar knob.
Tip of
Bar
Back
view of
clutch
cover
