Sanicompact®comfort
EN
IMPORTANT ADDITIONAL INFORMATION
INTRODUCTION
I
SANICOMPACT COMFORT
hung toilet with an internal macerator/
pump to which you can also connect a
sink. The SANICOMPACT COMFORT
can only be installed with the special
support bracket supplied. SANICOMPACT
COMFORT
® is meant for use in residencial
applications. Installed and used correctly,
SANICOMPACT COMFORT
reliable and consistent service.
WARNING: This is a general warning that
failure to follow instructions could result
in poor functioning of the unit.
PRINCIPLES OF OPERATION
SANICOMPACT COMFORT
by an electronic program with two
functions.
• It has a macerating and pumping
function. To begin press on either side
of the push button (light grey: small
flush, dark grey: large flush) integrated
to the bowl.
• The pump cycle cleans the washbasin
waste. This is an automatic operation
that will activate as long as water from
the washbasin enters the unit.
LIST OF ACCESSORIES
II
SUPPLIED
See page 3
DIMENSIONS
III
See page 7
TECHNICAL DATA
IV
APPLICATION 1 WC + 1 sink
Maximum vertical pumpinq
Voltaqe
Frequency
Normal power ratinq
Maximum current consumption
Maximum water temperature
Minimum water pressure
Electric class
Deqree of protection
Net weiqht (with frame)
Horse power
WARNING: Only installations conforming to
the above specifications are acceptable.
is a wall
®
PERFORMANCE CURVE
V
®
See page 6
VERTICAL/HORIZONTAL
VI
PUMPING COMBINATIONS
See page 6
will give you
®
INSTALLATION PREPARATIONS
VII
WARNING: Before proceeding with the
installation of SANICOMPACT COMFORT
ensure that the wall is sufficiently strong
to support the unit. (Each fastening
is controlled
®
should have a tensile strength of 120 kg
(264 lbs).
Note that the SANICOMPACT COMFORT
can handle up to a maximum of 250 lbs
(weight limit).
SETTING THE HEIGHT OF THE
7a
SUPPORT FRAME
1. Place the frame against the wall.
2. Adjust to a comfortable height using
the vertical threaded feet. See drawings
1 and 2. (Note ADA requirements is
minimum 17-inches from floor to top
of toilet seat.
3. Fully tighten the feet rod nuts.
ATTACHING THE FRAME TO
7b
THE WALL
1. Mark the screw holes with a pencil.
WARNING: If your wall is not perfectly
vertical, shim the frame with washers (as
per drawing #4).
2. Drill a 1/4-inch pilot hole.
9 feet
3. Use 4 (3/8 x 3-inch) lag screws to
110-115 V
fasten frame to the stud wall.
60 Hz
4. Use all 4 holes to fasten the frame to
815 W
the wall.
7.2 A
PREPARING THE SUPPORT
7c
110°F
FRAME
45psi
1. Separate the bowl and template
I
the frame (shipped together for transit
IP44
purposes).
90 lbs
2. Assemble the threaded rods
0.5 HP
drawing 5.
3. Adjust threaded rods to 2.5 inches
WARNING: The distance between the sup-
porting wall and the front of the support
frame should not exceed 4-inches (100
mm). The frame should fit flat against the
wall.
7d
1. Install a 1/2-inch water supply.
2. The water supply pipe must be fitted
3. The pipe should terminate with a shut
,
®
4. The water supply pipe should be
®
5. For correct rinsing of the bowl, the
7e
1. The discharge pipe should be either
2. Put the end of the pipe through the
IMPORTANT: Use only long sweeping
elbows for the discharge pipe or a couple
of 45 degree elbows back to back when
chan ging direction. Do not use 90 degree
elbows.
7f
1. Connect sink waste via 1 1/4-inch ABS
2. Feed the waste pipe through either the
IMPORTANT: The drain pipe corning from
the sink should connect into the special
connector (provided).
from
E
as per
D
1
away from the frame.
WATER SUPPLY
in the upper part of the frame.
off valve (1/2-inch sweat x 3/8-inch
compression) with the handle of the
stop valve just visible below the top of
the frame.
fastened with clamps against the wall
in order to avoid any movements while
connecting the device.
water pressure must be minimum 45
PSI (3,10 bar)
DISCHARGE CONNECTION
copper or CPVC or PVC solvent weld
pipe in 1-inch diameter.
upper part of the frame.
CONNECTION OF SINK
or PVC pipe.
left or right hand side holes provided.
