ELECTRICAL CONNECTION
WARNING: risk of electric shock- this
pump is supplied with a grounding
c o n d u c t o r a n d g r o u n d i n g
attachment plug to reduce the risk of
electrical shock. Be certain that it is
connected only to a properly grounded
- type receptacle.
• P l u g th e e le c t ri ca l cord in to a
receptacle protected by a 15 Amp GFCI
circuit breaker.
• Due to service requirements this
electrical supply should feed the
SANICOMPACT COMFORT
MOUNTING THE BOWL AND
VIII
CUTTING OUT THE PANEL
IMPORTANT: Make sure to install the toilet
seat before mounting the bowl.
1. When the frame is placed against a wall;
cut strips of cement board (or sheet
rock) to cover the sides and front of the
frame.
2. When the frame is inside a wall, board
the entire opening.
Note: Make a 1-inch (25 mm) hole in
the board (corresponding with the
threaded rods). This will allow you to
adjust the depth of the rod later.
IMPORTANT: Make sure to have an access
panel in order to minimize any extra work
in case of service.
3. Place the template
E
wall, positioning the holes for the WC
supports rods accordingly.
4. Trace the inner shape of the template
onto the front.
5. Remove the template and cut out the
E
opening as traced, being careful not to
cut any pipe or wire.
Note: If you are tilling the wall, the tiles
will have to be cut out in the shape of the
inner opening.
6. Finish the support wall and place the
template onto the screws.
CONNECTIONS
IX
WARNING: Before making the various
connections, check the following:
1. Ensure that the threaded rods are
correctly spaced and the dimensions
in drawing adhered to, otherwise the
7c
screw covers will not fit.
2. Put the template in place onto the
E
threaded rods.
CONNECTION OF SINK
9a
1. Remove the cap of the waste inlet
located underneath the water inlet.
2. Connect the rubber waste connection
to the spigot with the correct clamp
N
and crimp it with either a set of pliers
J
t y p e or crimpers.
3. Connect the other end of the connecter
to the 1 1/4-inch (32 mm) end of sink
N
waste pipe and secure it with clip
9b DISCHARGE CONNECTION
1. Insert the larger end of the plastic
discharge elbow
discharge hose coming out from the
top of the pump.
2. Rotate the discharge to any direction
only.
®
and secure the base of the elbow with
a clamp
3. Connect the flexible hose
smaller end of the discharge elbow and
secure with a clamp
CONNECTION OF THE
9c
WATER SUPPLY
Connect the water supply hose to the
compression fitting.
ELECTRICAL CONNECTION
9d
Plug the cord into the receptacle.
MOUNTING THE BOWL
X
Once the connections have been made,
1. Ensure that the clear tube
the threaded rods.
2. Push the bowl onto the threaded rods;
secure the nuts (with washers) without
over-tightening them.
against the
START-UP AND PROGRAMMING
XI
START-UP
11a
1. Plug in the power socket. Wait 20
seconds: appliance initializing. Open
the water tap to rinse well. Start the
normal flush by pressing the dark grey
button. Put a few sheets of toilet paper
down in the bowl and flush again.
Note: This unit does not need to be
vented.
2. Turn on the sink tap. The unit should
sink activate automatically.
3. Check the water tightness of all
connections from your access panel.
WARNING: Leaking faucets will cause the
unit to activate automatically.
PROGRAMMING
11b
T h e l e n g t h o f yo u r SA N I CO M PAC T
COMFORT
cycle you choose.
Eco flush (by default, light grey button):
19 seconds and 1 gallon (3.8L): rinsing of the
bowl for 10 seconds, the pump works for
7 seconds (for 7 seconds, the bowl continues
to fill), then the bowl fills again for 2 seconds.
into the rubber
H
.
I
to the
H
.
J
is still on
F
's flush varies according to which
®
2
You can lengthen the first rinse of the eco
flush to 16 seconds if the default flush is
not enough.
Normal flush (dark grey button):
25 seconds and 1.32 gallons (5L): The bowl
is rinsed for 16 seconds, the pump works
for 7 seconds (for 7 seconds, the bowl
.
J
continues to fill) then the bowl fills again
for 2 seconds.
To re-program:
Note: Only the ECO option can be
reprogrammed.
• Hold the ECO button (light grey button)
down for 5 seconds.
• The motor works for 2 seconds, this
means you have entered programming
mode.
• Each time you press the dark grey
button you increase the length of the
ECO flush by 1 second: each time you
press it will be validated by the motor
running for a short period.
• Each time you press the grey button
you decrease the length of the flush
by 1 second: each time you press it will
be validated by the motor running for
a short period.
To exit programming mode:
• Wait for 5 seconds without pressing
any buttons.
The motor runs for 2 seconds, this means
that you have left programming mode.
Comment 1: the minimum length of the
first rinsing flush for the normal flush is 19
seconds (default programming) and the
maximum length is 25 seconds.
Comment 2: the normal flush cannot be
modified.
USAGE
XII
The SANICOMPACT COMFORT
macerator does not require any special
maintenance.
W A R N I N G : T h e
COMFORT should only be used for the
®
evacuation of normal human waste, toilet
paper and household toilet cleaners.
Damage may occur to the motor if the
following are disposed of via the toilet:
cotton wool, tampons, sanitary napkins,
wet wipes, kitchen towels, condoms,
dental floss as well as other fabric or
hard objects. Solvents, acids and other
chemicals can also cause damage to the
unit, and will invalidate the warranty.
WARNING: In case of prolonged power
failure, or going on vacation, please
close the shut off valve of the the sink
and water supply.
pump/
®
S A N I C O M PA C T
