Create AIR STAND EASY Manuel D'utilisation page 7

1. Security grilles
2. Fan blade
3. Extension stick
4. Height adjustment knob
5. Fan base
6. Speed control
7. Oscillation knob
8. Fixing bolt
BASE AS SE MB LY
LIST OF PARTS
1
2
3
4
5
ASSEMBLY INSTRUCTIONS
1. Loosen and remove the base lock screw and washers from
the bottom of the bar.
2. Fit the bar into the recess on the top side of the base and
while holding it, flip it over to access the bottom.
3. Align the large washer, small washer, and base lock screw
with the hole. Turn the base lock screw to finish fixing the
base to the fan body.
4. Then turn it upside down and place it on a stable flat surface.
5. Loosen the height adjustment knob and pull out the exten-
sion pole to the desired height.
6. Then retighten the knob so the extension pole is secure.
6
7
8
7
E NGLI SH
