• If a piston is not used with the barrel, an inline filter (881-000-000) must be
installed on the receiver head to help prevent fluids from being sucked back
into the unit. Also do not overfill the barrel and to lay the barrel on its side
• Do not smoke or use open flame when flammable materials are being dispensed
• This equipment is for indoor use only
2
SYMBOL DEFINITIONS
Symbol
Definition
Power On/Off
Cycle Mode
Timer
Vacuum
Pressure
SPECIFICATIONS
3
Size
Weight
Input Voltage
Rated Power
Air Input
Pollution Degree
Installation Category
Indoor Use
Operating Temperature
Storage Temperature
Max. Relative Humidity
Air Output
Vacuum
Timer
Cycle Mode
Timing Repeat Tolerance
Cycle Rate
LCD
152mm X 165mm X 178mm
(6" X 6.5" X 7")
1.2 kg (2.6 lbs)
24VDC
10W
100 psi (6.9 bar) Max.
II
I
Altitude up to 2,000m (6,562ft)
0˚C to 50˚C (32˚F to 122˚F)
-10˚C to 60˚C (14˚F to 140˚F)
80% for temperature up to 31˚C (87.8˚F) Decreasing
linearly to 50% relative humility at 40˚C (104˚F)
TS350 = 0-100 psi (0-6.9 bar)
TS355 = 0-15 psi (0-1.03 bar)
406mm (16") of Hg
0.008-60.000 seconds
Timed, Interrupt, Teach, Purge
+/- 0.001%
1,200 cycles/min.
20 X 4 display segments
3
