S+S Regeltechnik THERMASGARD ALTM 2-Modbus -T3 Notice D'instruction page 8

G U
THERMASGARD
Schematic diagram
Plug for
display
1 2 3 4 5 6 7 8
SHD
DIP A: Bus address
DIP B: Bus parameters
(Baud rate, parity...)
Telegram indicator
Reception (LED green)
Error (LED red)
Manual offset adjustment
The sensors are pre-set and calibrated at the factory.
For subsequent adjustment of the measured value,
there is an offset potentiometer (A) available.
Range of adjustment: (A) approx. ± 10 °C ⁄ ± 18 °F
Type ⁄ WG01
A LT M 2 - M o d b u s -T 3
A LT M 2 - M o d b u s -T 3 LCD
Extra charge:
Note:
ACCESSORIES
KA2 -Modbus
LA -Modbus
WLP-1
®
ALTM 2-Modbus-T3
THERMASGARD
ON
A offset
1 2 3 4 5 6 7 8
address
ON
DIP B
1 2 3 4 5 6
mode
SHD
LED (internal status)
Offset correction
Shielding
Measuring range
temperature
–50...+150 °C / – 58...+ 302 °F
–50...+150 °C / – 58...+ 302 °F
Protection type IP 68 (sensor sleeve watertight compound-filled)
per running metre of connecting lead (silicone / PTFE / glass fibre)
Cable connection with M12 connector according to DIN EN 61076-2-101
System of units SI (default) or imperial (can be changed via Modbus).
Communication adapter (USB/RS485) for system connection
Line termination device (with terminating resistor) as an active bus termination
Heat-conductive paste, silicone-free
® Pin assignment
xx - Modbus - T3
(M12)
DIP A
Output Type
Modbus Remote sensor
Modbus Remote sensor
8
MALE
2
3 5 1
4
1
+UB
2
Modbus A
3
–UB GND
4
Modbus B
5
Shield
Display Item No.
1101-62B 6- 0210- 000
■ 1101-62B 6- 4210- 000
1906- 1200- 0000- 100
1906 -1300- 0000- 100
7100- 0060- 1000- 000
Rev. Data - V40
®
THERMASGARD
xx - Modbus - T3
FEMALE
2
1 5 3
4
on request
on request
