Parking Lot Sensor | PLS

3 Technical specifications

Table 1 Device specifications - Parking Lot Sensor PLS with TPS110 sensor core
P
ROPERTIES
Temperature range
Humidity
Protection class
Dimensions
Battery life
LoRa frequencies and LoRa Channel Plans
(RP002-1.0.0)
Radar frequency
Mass
Additional information can be found in the datasheet on the website at
sensor/downloads/.
Risk of interference to other radio services and malfunction.
Operation of the TPS110 variant out of the Target Markets specified in Chapter 4 can cause disturbance
of other services and can be subject of legal prosecution. Regulatory notices for other countries are
included in Chapter 4 of the English part of this user manual.
⇒ Ensure that TPS110 variants are operated only in the target markets with a valid approval statement.
⇒ Ensure that it is connected to LoRa gateways that are certified for operation in the target markets and
support the regional channel plans published by the LoRa Alliance.
© Bosch Connected Devices and Solutions GmbH 2020. All rights reserved, also regarding and disposal, exploitation, reproduction, editing,
distribution, as well as in the event of application for industrial property rights.
V
ALUES
-30 °C to 65 °C
0 – 97%
IP67/IPx9K
⌀: 145.4 mm
H: 30.5 mm
Up to 5 years
TPS110 EU: 863-865/868-868.6/869.4-869.65 MHz (EU868)
Transmitting power max. 14 dBm ERP
TPS110 IN: 865-867 MHz (IN865)
Transmitting power max. 14 dBm ERP
TPS110 JP: 920-923.4 MHz (AS923)
Transmitting power max. 14 dBm ERP
2.4-2.4835 GHz
Transmission power max. -28 dBm EIRP
191 g
https://www.bosch-connectivity.com/parking-lot-
Warning
11 | 16
