EQUIPMENT DESCRIPTION

2.1.

Bath module with its corresponding equipment.

AIR INTAKE
NOZZLE
BODY
2.2. Filtering, powering, air massage, water massage, heating and operation
equipment.
FILTER
OPER.
CABINET
WATER MASSAGE
SUMP
HEAT EXCHANGER
PUMP
3
JETS
NEUMATIC
KEYS
IMPULSION
PIPE
Generic figure
FLOW
DETECTOR
AIR PUMP
FILTER PUMP
Generic figure
