2. Layout and items supplied

2.1 Layout (Fig. 1a/1b)
1. Pulley
2. Draw hook
3. Snap lock
4. Selector lever
5. Hand crank
6. Metal clamp for hand crank (for TC-WI 800
only)
2.2 Items supplied
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Original operating instructions

3. Proper use

The hand rope winch is a device for moving loads
horizontally.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Anl_TC_WI_500_800_SPK9.indb 14 Anl_TC_WI_500_800_SPK9.indb 14
GB

4. Technical data

4.1 TC-WI 500
Max. tensile load in kg: ................................. 500
Cable length in m: .......................................... 10
Cable diameter in mm: .................................. 4.2
4.2 TC-WI 800
Max. tensile load in kg: ................................. 800
Cable length in m: .......................................... 20
Cable diameter in mm: .................................. 4.8

5. Before using the equipment

•
Before you use the equipment to pull a load,
you must familiarize yourself with the way in
which the equipment works "without a load".
•
Install the winch on a level and stable surface.
For greater stability and safety, the winch
should be secured to the base plate using
size M10 screws and washers screwed into
the three mounting holes in the base plate.
•
Fit the hand crank (5) to the winch and secu-
re it using the supplied self-locking nuts.
•
If the equipment is the TC-WI 800, fit the me-
tal clamp (6) as shown in Fig. 2.
•
The snap lock (3) on the draw hook (2) must
always be closed during operation, to prevent
the load being released abruptly.
6. Operation
Warning: Only pull loads horizontally.
Caution: Wear gloves to protect your hands.
Warning: Always leave at least 3 full winds of the
cable on the pulley when you work with the cable
winch.
6.1 Fastening the cable winch to the load
(Fig. 3)
•
Move the selector lever (4) to the lower posi-
tion to enable the cable to be wound up using
the hand crank (5) (turn counterclockwise).
•
Attach the draw hook (2) securely to the load
you intend to pull.
•
Make sure that the snap lock (3) is closed.
- 14 -
