Contest OCTODANGLE Guide De L'utilisateur page 18

OCTODANGLE - LEDs multi beams light DJ effect
6.2 - 6 channel mode (continuation and end)
Channel DMX values
000-004
CH3 : LED derby 005-249
250-255
000-004
005-127
CH4 Rot derby
128-133
134-255
000-009
010-034
035-059
060-084
085-108
109-132
CH5 : FLASH
133-156
157-180
181-204
205-228
229-250
251-255
000-009
CH6 : UV 010-249
250-255
7 - DMX cabling and addressing for each mode
Unit 1
DMX mode
1 channel
6 channel
Page 18
Function
No function
Strobe
Audio strobe mode
Stop
Clockwise rotation
Stop
Counterclockwise rotation
Blackout
Animation 1
Animation 2
Animation 3
Animation 4
Animation 5
Animation 6
Animation 7
Animation 8
Animation 9
Animation 10
Full on
Blackout
Strobe
Full on
Unit 2
Unit 1 address
1
1
Unit 3
Unit 2 address
2
7
Action
(from slow to fast) (max 30Hz)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
(from slow to fast)
Unit 4
Unit 3 address AUnit 4 address
3
13
4
19
