Technical Specifications - Contest OCTODANGLE Guide De L'utilisateur

2 - Introduction
The OCTODANGLE is an animation effect with RGBWA LEDs and RGBWUV flashes
The mains features are :
Very wide multi-beams projections
Powerful colour flashes
Many different modes

3 - Technical specifications

• Light source :
• 5 LEDs (RGBWA) 5W
• 8 LEDs colours+UV (R/G/B/W+UV) 2W flashes
• 3 modes :
- DMX (1/6 channels)
- Music sensitive (master) via built in microphone
- Automatic
• Slave
• LED display to choose modes
• Forced ventilation
• Power consumption : 66W average
• Power supply : AC 100/240V - 50/60Hz
• DMX input and output
• Power input and output via IEC socket
• Black metal housing
• Suspension bracket
• Dimensions : 313 x 170 x 245 mm
• Net weight : 4.2 Kg
OCTODANGLE - LEDs multi beams light DJ effect
Page 13
