Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instructions for
the safe, proper and economic operation of the product,
for avoiding danger, for minimising repair costs and
downtimes and for increasing the reliability and extend-
ing the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations applica-
ble to the operation of the product in your country.
Keep the operating manual package with the power tool
at all times and store it in a plastic cover to protect it
from dirt and moisture. They must be read and carefully
observed by all operating personnel before starting the
work.
The product may only be used by personnel who have
been trained to use it and who have been instructed with
respect to the associated hazards.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that oc-
cur due to a failure to observe this manual and the safe-
ty instructions.
3
Product description (Fig. 1-10)
1.
Water filler port
2.
Spark plug connector
2a.
Spark plug
3.
Choke
3a.
Fuel pump "primer"
4.
Exhaust pipe
5.
Pull starter
6.
Fuel tank
7.
Fuel filler cap
8.
Wing screw
9.
Air filter cover
9a.
Air filter
10.
Suction connection
11.
Off switch
12.
Pressure connection
13.
Throttle
14.
Water drain plug
15.
Hose adapter
16.
Union nut
17.
Seal
18.
Hose clamps
19.
Pre-filter
20.
Spark plug wrench
4
Scope of delivery (Fig. 2)
Item Quantity
Designation
15
2 x
Hose adapter
16
2 x
Union nut
17
2 x
Seal
18
3 x
Hose clamp
19
1 x
Pre-filter
20
1 x
Spark plug wrench
1 x
Operating manual
5
Proper use
The product is suitable for watering and irrigating green
areas, vegetable beds and gardens and for operating
lawn sprinklers. Suitable pumping media are clear water
(fresh water), rainwater and light detergent/soap solu-
tions. With a pre-filter, water can be drawn from ponds,
streams, rainwater barrels, rainwater cisterns and wells.
The maximum temperature of the pumped liquid must
not exceed +35°C in continuous operation.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instructions
and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about
potential dangers.
GB / IE / NI / CY / MT
|
