Stihl RMA 443.2 PV Notice D'emploi page 38

English
is discharged, the machine automatically
switches to the battery in the second battery
compartment (4). There must always be a bat‐
tery in the first battery compartment (3) when
working.
RMA 443 VC and RMA 448 VC:
The RMA 443 VC and RMA 448 VC lawn mow‐
ers are equipped with a battery compartment (3)
and a transport compartment (4). The lawn mow‐
ers can only be operated with the battery in bat‐
tery compartment (3). A replacement battery can
be carried in transport compartment (4).
► Place the lawn mower on a level surface.
► Open flap (1) as far as it will go and hold it
open.
► Push battery (2) into battery compartment (3)
as far as it will go.
Battery (2) engages with a click and is locked
in place.
► If a second battery is to be carried: Fit the bat‐
tery in battery compartment (3) or transport
compartment (4).
The battery engages with a click and is locked
in place.
► Close flap (1).
10.2 Removing the Battery
► Place the lawn mower on a level surface.
► Open flap (1) as far as the stop and hold.
38
11 Inserting and Removing the Activation Key
► Press locking lever (2).
Battery (3) is released.
► Remove battery (3).
► Close flap (1).
11 Inserting and Removing
the Activation Key
11.1 Inserting the Activation Key
► Open flap (1) as far as the stop and hold.
► Insert activation key (2) in key receptacle (3).
► Close flap (1).
11.2 Removing the Activation Key
► Open the flap as far as the stop and hold.
► Pull out the activation key.
► Close the flap.
► Keep the activation key out of the reach of
children.
12 Switching the Lawn Mower
On and Off
12.1 Activating and Deactivating the
Blade
12.1.1 Activating the Blade
► Place the lawn mower on a level surface.
0478-131-9948-D
