Tectro TP 4020 Manuel D'utilisation page 71

6. Fan speed control
7. Timer control
8. Cooling mode indicator
9. Dehumidifier mode indicator
10. Air circulation mode indicator
11. Heating mode indicator (TPH 4026)
12. Reservoir full indicator
13. High fan speed indicator
14. Low fan speed indicator
15. Timer setting indicator
16. Remote control receiver
Insert the plug into the wall outlet.
Press the -button B to switch on the air conditioner.
• If the ambient temperature is higher than 25ºC, the unit will work in
cooling mode.
• If the ambient temperature is < 25ºC, the unit will work in air circulation
mode.
With -button 5 you can change the operating mode of the unit.
By pressing the -button the following modes appear:
Cooling mode H
Dehumidifying mode I
Air circulation mode J
Heating mode (TPH 4026) K
COOLING
When the unit is in the cooling mode, the following functions apply:
• The fan speed can be adjusted by pressing the
Maximum setting 
Lowest setting 
• The temperature can be set by pressing the 3
anywhere between 16°C en 31°C. After flashing 4 times the current room
temperature is shown. In automatic mode the unit selects the fan speed
based on the room temperature. The speed cannot be adjusted.
HEATING (TPH 4026)
When the unit is in the heating mode, the following functions apply:
• The fan speed can be adjusted by pressing the
Maximum setting 
Lowest setting 
• The temperature can be set by pressing the 3
anywhere between 16°C en 31°C. After flashing 4 times the current room
temperature is shown. In automatic mode the unit selects the fan speed
based on the room temperature. The speed cannot be adjusted.
-button 6
and 4 buttons,
-button 6
and 4 buttons,
4
71
