IV. GETTING STARTED
Before any intervention on product, ensure that switch is set on the "OFF" position,
remove the battery and unplug the charger from its power source.
4.1- Unpacking
- Remove product from its packaging.
- Check that tool and accessories are not damage.
Content: - 1pc rotary hammer
- 1pc Li-ion battery 20V 4.0A
- 1pc quick charger
- 1pc flat chisel + 1pc point chisel
- 4pcs SDS drill 8/10/12/16
- 1pc depth scale
- 1pc auxiliary handle
- 1 instructions manual
4.2- Assembly
The tool requires minor assembly prior to first time use.
Ensure to remove the battery before proceeding with any intervention.
4.2.1- Auxiliary handle assembly (8)
To fit the auxiliary handle (8), unscrew the handle to open the
clamping ring.
Pull open the clamping ring until it can pass over the chuck and set
onto the drill body.
Re-screw the handle firmly.
Note1: you can assemble the auxiliary handle as desired: either on
the right or on the left.
Note2: Only use the tool with the auxiliary handle assembled.
4.2.2- Depth gauge assembly
Unscrew the auxiliary handle.
 Insert the depth gauge through the opening located on the upper
part of the auxiliary handle.
 Re-screw the handle.
4.2.3- Depth gauge adjustment
To adjust the depth gauge to the required working depth, proceed as
follows:
Measure back from the drill tip and move the depth stop back to the
required measured depth.
The end of the depth stop will come into contact with the work
surface when the required depth of hole is reached.
4.3- Battery & Charger
Note: The battery is supplied partially charged. To ensure proper running of the tool, completely charge
the battery in the provided charger before first time use.
Tips to ensure optimal battery life
- Do not to drop, hit, or damage the battery.
=>
=>
