Miele PWM 520 EH Schéma D'installation page 21

Publicité

Les langues disponibles

Les langues disponibles

Installation dimensions
Casing width (without add-on components)
Casing height (without add-on components)
Casing depth (without add-on components)
Overall machine width
Overall machine height
Overall machine depth
Minimum width of transport opening
Minimum safety distance between wall and rear of machine
Door opening diameter
Door opening angle
Anchoring
Standard
Required anchor points
DIN 571 wood screw (diameter x length)
Rawl plugs (diameter x length)
With base (APWM)
Required anchor points
DIN 571 wood screw (diameter x length)
Rawl plugs (diameter x length)
Concrete plinth
Required anchor points
DIN 571 wood screw (diameter x length)
Rawl plugs (diameter x length)
Transport data, weight and floor load
Packaging width
Packaging height
Packaging depth
Gross volume
Gross weight*
Net weight*
Maximum floor load during operation*
*depending on equipment configuration
Emissions data
Workplace-related sound pressure level, washing
Sound power level, washing
Workplace-related sound pressure level, spinning
Sound power level, spinning
Average heat dissipation rate to installation site
Emission sound pressure level
en - Technical details
36 1/4" (920 mm)
56 15/16" (1447 mm)
33 3/4" (857 mm)
36 3/8" (924 mm)
57 1/16" (1450 mm)
41 1/2" (1053 mm)
40 9/16" (1030 mm)
54 3/8" (1380 mm)
16 5/16" (415 mm)
1/2" x 3 1/2" (12 mm x 90 mm)
5/8" x 3 1/8" (16 mm x 80 mm)
1/2" x 3 1/2" (12 mm x 90 mm)
5/8" x 3 1/8" (16 mm x 80 mm)
1/2" x 3 1/2" (12 mm x 90 mm)
5/8" x 3 1/8" (16 mm x 80 mm)
62 3/8" (1585 mm)
44 1/2" (1130 mm)
346.2 lb / 178.6 lb (157 kg / 81 kg)
319.7 lb / 152.1 lb (145 kg / 69 kg)
65 dB (A) re 20 μPa
180°
2
4
2
43" (1090 mm)
2 x 744 L
3250 N
50 dB (A)
59.2 dB (A)
63 dB (A)
73.7 dB (A)
2.3 MJ/h
21
