Connecting Components with HDMI

Game console
Connect your components to the appropriate jacks. The default input assignments are shown below.
Jack
Input HDMI IN 1
HDMI IN 2
HDMI IN 3
HDMI IN 4
Output HDMI OUT
See also:
• "Connection Tips and Video Signal Path"
• "About HDMI" (➔
• "Using an RIHD-compatible TV, Player, or Recorder"
■
Audio Return Channel (ARC) function
Audio Return Channel (ARC) function enables an HDMI capable TV to send the audio stream to the HDMI OUT of the
AV receiver.
• This function can be used when:
– your TV is ARC capable, and
– the TV/CD input selector is selected, and
– "HDMI Control (RIHD)" is set to
– "Audio Return Channel" is set to "Auto"
Tip
• To listen to audio received by the HDMI IN jacks through your TV's speakers:
– Set the "HDMI Control (RIHD)" setting to "On"
– Set the "Audio TV Out" setting to "On"
(RIHD)" setting to "Off".
– Set your Blu-ray Disc/DVD player's HDMI audio output setting to PCM.
– To listen to TV audio through the AV receiver, see "Connecting Your Components"
Note
• When listening to an HDMI component through the AV receiver, set the HDMI component so that its video can be seen on the TV
screen (on the TV, select the input of the HDMI component connected to the AV receiver). If the TV power is off or the TV is set to
another input source, this may result in no sound from the AV receiver or the sound may be cut off.
• As the "Audio TV Out" setting is set to "On"
receiver's speakers if you adjust the volume of the AV receiver. Similarly, as the
page 54) to hear from the speakers of an p-compatible TV, the AV receiver's speakers will produce sound if you adjust
(➔
the volume of the AV receiver, while the TV speakers will be muted. To stop the AV receiver's speakers from producing sound, you
can either change the settings on the AV receiver or on the TV, or turn down the volume of the AV receiver.
En
16
VCR or DVD recorder/Digital Video Recorder
Satellite/cable set-top box, etc.
Components
Blu-ray Disc/DVD player
VCR or DVD recorder/Digital Video Recorder
Satellite/cable set-top box, etc.
Game console
TV, projector, etc.
page 79)
(➔
page 81)
"On"(➔ page 54), and
(➔ page 55).
(➔
page 55) when the TV is not compatible with p, or the "HDMI Control
(➔
page 55) to hear from your TV speakers, the sound will also be output from the AV
(➔
Blu-ray Disc/DVD player
✔: Assignment can be changed
page 82)
(➔
page 54) for an p-compatible TV.
(➔
"
HDMI Control (RIHD)" setting is set to
TV, projector,
etc.
(➔
Assignable
✔
✔
✔
✔
page 17).
page 42).
" "
On
