PUT THE GASKET ON THE DUCT ADAPTER
1. Put the duct adapter gasket on the duct adapter.
Caution:
•
Make sure to use the correct gasket.
•
Make sure that the gasket is properly attached before you proceed to the next
step.
ATTACH THE DUCT ADAPTER TO THE HOOD
1. Slide the duct adapter on the hood.
2. Install the screws.
3. Tighten the screws to fasten the duct adapter.
ATTACH THE CORNER PIPE TO THE DUCT ADAPTER
1. Slide the corner pipe over the duct adapter.
2. Put tape around the edge of the corner pipe to attach it to the duct adapter.
PUT THE APPLIANCE IN THE WORKTOP
1. Tilt the appliance. Make sure that the air duct on the rear of the appliance points down.
2. Put the rear of the appliance in the opening of the worktop.
3. Lower the front of the appliance on the worktop.
PUT THE WATER DRAINAGE PLUG IN THE HOOD
1. Put the plugs into the holes.
2. Make sure that the plugs are installed correctly. Refer to the figure.
INSTALL THE FILTERS AND THE GRILLE
(Figure 11)
You can install the appliance so that the air is extracted or recirculated. Refer to section
extraction system
. Select the procedure for air extraction or recirculation to install the filters and the grille.
Extraction
1. Collect the installation parts.
2. Pull the carbon filter cover straight up to remove it.
3. Pull the tabs of the carbon filters to remove the filters.
4. Put the grease filter in the cavity of the induction plate.
5. Put the grille on top of the grease filter.
Recirculation
1. Collect the installation parts.
2. Pull the carbon filter cover straight up to remove it.
3. Turn the carbon filter so that the tabs point to the right side.
4. Put the carbon filters in the hood below the original position of the carbon filter cover.
5. Push the carbon filters to the left side into the correct position.
Caution:
Make sure that the carbon filters are installed correctly.
(Figure 17)
(Figure 18)
(Figure 19)
(Figure 20)
(Figure 21)
Working principle of the
English
•
31
