EN
Description
ID
Sof Fail Protection
PLL
Poff Protection
OOCP Protection
OVP Protection
UVP Protection
OTP Protection
UTP Protection
OLPH Protection
OLPL Protection
The following data shows the function code detail setting value.
Note:
Below setting value will go back to default value by switching on / off
the inverter.
5-3-2-1. FUNC 0 : OVP setting
SETT <value>
15.0 ~ 16.5
30.0 ~ 33.0
60.0 ~ 66.0
5-3-2-2. FUNC 1 : OVP Recovery
SETT <value>
13.5 ~ 14.5
27.0 ~ 29.0
54.0 ~ 58.0
5-3-2-3. FUNC 2 : UVP setting
SETT <value>
10.5 ~ 11.5
21.0 ~ 23.0
42.0 ~ 46.0
36
All manuals and user guides at all-guides.com
SP-3000 ~ SP-4000 Status Definition
Definition
ID: ID Connection Error
Sof Fail: Soft Start Fail
PLL: Phase lock loop
Poff: Power off
OOCP: Output Over Current Protection (Over Load >
200%)
OVP: Over Voltage Protection
UVP: Under Voltage Protection
OTP: Over Temperature Protection
UTP: Under Temperature Protection
OLPH: Over Load Protection High (116~200%)
OLPL: Over Load Protection Low (101~115%)
Table 36. SP-3000 ~ SP-4000 Status Definition
Default
16.5V <16.5>
33.0V <33.0>
66.0V <66.0>
Table 37. OVP setting
Default
14.5V <14.5>
29.0V <29.0>
58.0V <58.0>
Table 38. OVP recovery
Default
10.5V <10.5>
21.0V <21.0>
42.0V <42.0>
Table 39. UVP setting
Model
SP series-112 / 212
SP series-124 / 224
SP series-148 / 248
Model
SP series-112 / 212
SP series-124 / 224
SP series-148 / 248
Model
SP series-112 / 212
SP series-124 / 224
SP series-148 / 248
