EN
Pin Number
4
5
6
7
8
3-1-5. AC output Interface
3-1-5-1. SP-700/1000/1500/2000 AC output interface
Socket Type
24
All manuals and user guides at all-guides.com
Signal Description
Bypass
Transfer Relay Driver Signal
12V
Internal power for TR40 controller
5V
Internal power for TR40 controller
The same polarity as the battery negative
GND
side
Reserved
--
Table 24. SP Series TRC Port : RJ-45.
Figure 11. Wiring between SP series and TR-40
Note! The detail information please refer to TR-40 user manual
Applicable Model
SP-700/1000-112**/124**/148
SP-1500/2000-112**/124**/148
