Electrical
Input
Input Under-Voltage Protection
Characteristics
Continuous Output Power
Maximum output Power (1Min)
Output
Characteristics
Short-Circuit Protection
Remote Controller Panel Unit
Signal and Control
Remote Control Terminal
Protection
Environment
Storage Temp. & Humidity
Safety & EMC
Dimension(WxHxD)
Weight
Cooling
AC Transfer Function Accessories
Note：
Voltage range：Please refer to Figure 3
Normal load Condition：Vin =25V/50V, Vo=200/220/230/240 VAC 80% load (PF=1.0)
Operating temperature：Please refer to Figure 4
Warning：This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
All manuals and user guides at all-guides.com
Specification
Item
Voltage
Input Over-Voltage
Protection
Voltage Range
No Load Current
Power Saving Mode
Surge Power (1Sec)
Frequency
Output Voltage
Efficiency max.
Output Waveform
LED Indicator
Dry Contact Terminal
Input Protection
AC Output Protection
Others
Operating Temp.
Storage Temp.
Safety Standards
④
EMC standards
E-mark
Table 12. SP-4000 for Output 100/110/115/120 VAC Specification.
Model No.
SP-4000-224
24VDC
33 ± 0.5VDC
21 ± 0.5VDC
21~33 VDC
≦2.0A @24VDC
<0.2A @24VDC
4000 VA (± 3%)
> 4000 VA~4600 VA (100%~115%)
< 8000 VA
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
200 / 220 / 230 / 240 VAC (± 3%)
(Dip Switch Selectable)
90%
1 Sec Shutdown
Pure Sine Wave (THD < 3%@ Normal Load)
CR-8 / CR-16 (optional)
Red / Orange / Green LED
By a relay
6-port Green terminal (for inverter ON / OFF)
Over / Under Voltage, Reverse Polarity
(Internal Fuse)
Short-Circuit, Overload
Over / Under Temperature Protection
(by Heat sink Temperature +80℃/-20℃)
-20 ℃~40 ℃
-30 ℃~70 ℃
10 ~95% RH
Certified EN 60950-1
Certified EN 55022 class A; EN 55024;
EN 61000-3-2, -3-3;
EN 61000-4-2, 3, 4, 5, 6, 8, 11
Certified CISPR 25; ISO 7637-2
255mm X 158mm X 462mm
10 KG
Temperature & Load Controlled cooling Fan
TR-40 (optional)
SP-4000-248
48VDC
66 ± 1.0VDC
42 ± 1.0VDC
42~66 VDC
≦1.0A @48VDC
<0.1A @48VDC
91%
17
