LoRaWAN MODBUS MASTER - Guide utilisateur / User guide version V1.0.0

3.4.2 Network registers

The list of registers below allows you to change the behaviour of the product application. This list is accessible in Provider mode following
execution of the ATT63 Provider command.
These registers must be handled with caution because they could cause problems of communication or of non-compliance with the legislation in
force.
Register Taille Description
(octets)
201 4 FSpreading Factor
(SF) by default
202 4 Band width
205 4 Transmission
power
206 4 Spreading Factor
(SF) maximum
207 4 ADR settings:
ADR_ACK_LIMIT
208 4 ADR settings:
ADR_ACK_DELAY
214 4 LORA APP-EUI
(first part – MSB)
215 4 LORA APP-EUI (se-
cond part – LSB)
216 4 LORA APP-KEY
(first part– MSB)
217 4 LORA APP-KEY
(second part –
MID MSB)
218 4 LORA APP-KEY
(third part – MID
LSB)
219 4 LORA APP-KEY
(fourth part – LSB)
Codage
Decimal Default: 12 (868) or 10 (915) depending on the reference of the product
Min/max: 4 to 12
Unit: None
Decimal Default: 0
Possibilities:
• 0=125kHz
• 1=250kHz
• 2=500kHz
Decimal Default: 14
Min/max : 2 to 14
Unit : dBm
Decimal Default: 12 (868) or 10 (915) depending on the reference of the product
Min/max: 5 to 12
Unit: None
Decimal Default : 64
Min/max : 1 to 64
Unit: none
Decimal Default : 32
Min/max : 1 to 32
Unit: none
Hexadecimal Default: 0
Key encoded on 16 characters. Each register contains a part of the key.
Used during the join phase in OTAA mode
Hexadecimal
E.g.:
APP-EUI = 0018B244 41524632
• S214 = 0018B244
• S215 = 41524632
Hexadecimal Default: 0
Key encoded on 32 byte characters. Each of the 4 registers contains 8 characters.
Used during the join phase in OTAA mode
Hexadecimal
E.g.:
APP-KEY = 0018B244 41524632 0018B200 00000912
Hexadecimal
• S216 = 0018B244
• S217= 41524632
• S218 = 0018B200
Hexadecimal
• S219 = 00000912
Details
FR
EN
Page 61 of 80
