GROUP S.P.A.
You can enter names in the directory by downloading them from a PC using Art.1249/A. To perform this operation, activate the download
function from the menu, connect the switchboard to the PC via the relevant serial cable, and start the download software.
ATTENTION: Only activate this function only when you want to download names from a PC. To disable the function, the
switchboard must be turned off by means of the ON/OFF key.
OPERATION
Starting condition:
standby.
Press the MENU key
Use the ▼ ▲ keys to select the desired
menu.
Press key
6
MNO
to select the desired option.
(DOWNLOAD NAMES FROM PC)
Press the ESC key
• AUTO MODE
The system can be set up to switch automatically from DAY mode to NIGHT mode at the times programmed by the user. A maximum of
four times can be set. These times allow the day to be divided into time bands during which the system operates in DAY mode or NIGHT mode.
It is extremely important to set the times for switching from one mode to another correctly;
TIME 1: determines the first mode switch: from NIGHT mode to DAY mode
TIME 2: determines the second mode switch: from DAY mode to NIGHT mode
TIME 3: determines the third mode switch: from NIGHT mode to DAY mode
TIME 4: determines the fourth mode switch: from DAY mode to NIGHT mode
Example:
NIGHT MODE
00:00
TIME 1:
All 4 TIMES must be set (as shown in the following example) even though only 2 switchovers are needed:
Example:
You want to configure the switchboard with the following parameters:
00:00 - 07:00 Day mode operation
07:00 - 24:00 Night mode operation
TIME 1: 00:00
NIGHT / DAY
TIME 2: 07:00
DAY / NIGHT
TIME 3: 24:00
NIGHT / DAY
TIME 4: 24:00
DAY / NIGHT
MT SB 01
30
All manuals and user guides at all-guides.com
ENTRY FROM A PC
DISPLAY
A
(----) 21:40
WED 12/03/07
1-CHANGE TIME
2-CHANGE DATE
6-DOWNLOAD
NAMES FROM PC
SERVICE
NON ACTIVE
Followed by:
6-DOWNLOAD
NAMES FROM PC
A
(----) 21:40
WED 12/03/07
DAY MODE
NIGHT MODE
TIME 2:
DESCRIPTION
The available options are displayed.
N.B: Once the service is activated if you
do not want to download the names you
must disable it by turning the
switchboard off.
You can now proceed to download the
names using Art. 1249/A.
The service is automatically disabled on
completion of the download.
DAY MODE
TIME 3:
TIME 4:
24:00
