OPERATION:
SELECTING DMX MODE
Press the MODE button repeatedly until "DMX MODE" appears in the upper
line of the display. Press ENTER, and the cursor appears in the lower line
of the display and then use the UP and DOWN buttons to select one of the
five DMX modes (02CH, 03CH1, 03CH2, 05CH, 08CH). Confirm with ENTER.
You will find tables with the channels of the different DMX modes on the
following pages of this manual.
DMX START ADDRESS
Press the MODE button repeatedly until "DMX ADDR" appears in the upper
line of the display. Press ENTER, and the cursor appears in the lower line
of the display and then use the UP and DOWN buttons to select the desired
DMX start address between 001 and 512. Confirm with ENTER.
LOCK FUNCTION
To protect the projector against accidental and unauthorised operation, there is a
possibility to lock the controls. Press the UP and DOWN buttons simultaneously for
5 seconds. The display now shows LOCKED and it is no longer possible to change
the settings of the projector using the control keys. To unlock, press the UP and
DOWN buttons simultaneously for 5 seconds. Now the display will change to the
previously displayed information.
AUTOLOCK
In addition to the ability to protect the projectors manually against
accidental or unauthorised operation, this function can also be carried out
automatically.
Press the MODE button until "AUTOLOCK" appears in the upper line of the
display. Press ENTER, and the cursor appears in the lower line of the display
and then use the UP and DOWN buttons to select the desired operating mode
"ON" or "OFF". Confirm with ENTER.
Select "AUTOLOCK ON" and the controls of the projector are locked automatically
after approx. 40 seconds and the lighting of the display goes out. To unlock, press
the UP and DOWN buttons simultaneously for 5 seconds. Now the display will
change to the previously displayed information.
NOTE: If the Autolock feature is disabled (AUTOLOCK OFF), the illumination
of the LC display will be switched off automatically after about 40 seconds of
inactivity. Pressing any one of the 4 control buttons will turn the illumination
of the LC display on again.
