R-box Multi RB 071.50 - Base Unit for Wall-mounted Water Tap CR 067
Features of R-box Multi
1. Easy and quick installation.
2. Easy-installation in solid and cavity wall.
3. The R-box itself and the upper, visible portion of water tap CR 067.00 are packaged and supplied
separately, which prevents damaging of the chrome-plated surface of the tap during transport and
handling of the goods.
Packing list
Please check whether all the items in the packing list are included in the box.
If any item is missed, please contact us or the local agent for help.
Remarks:
The accessories might be changed without in advance notifi cation when the change doesn't aff ect the usage.
The appearance and dimension of the product are subjected to the real product. The drawing or photo is for reference only.
You could fi nd it at www.ravak.cz/cz/vodovodni baterie
Číslo
DESCRIPTION
1.)
Indicating board
2.)
Allen head Screw
3.)
Plus
4.)
Sealing board for E-box
5.)
Ring for sealing board
6.)
Plaster guard
7.)
R-box (Pre-embedded part) 1
8.)
Supporting stand
9.)
Expansion screw
10.)
Allen Key
11.)
Nut
All manuals and user guides at all-guides.com
Mounting instruction
QTY(PC)
1
6
1
2
9
1
1
1
4
1
1
7
8
11
6
5
4
3
10
2
1
