2013-05-01
3.2 Connection diagram
1. The electrical connection must only be carried out by qualified personnel.
V
2. For safety reasons, the device must only be connected to low voltages complying with
the SELV or PELV definition because voltage supply and analog inputs are not electrically
isolated !
Type 701066/XXX-XX
Relay K3
Option 2: RS 485
RxD/TxD +
RxD/TxD -
1
2
13
14
15
S
Ö
P
1
Relay K1
16A/250V AC
1. The switching positions of the instrument relays shown here (dotted line) represent the "relay de-energized" condition.
All manuals and user guides at all-guides.com
1
1
Relay K2
8A/250V AC
8A/250V AC
S
S
P
P
5
4
7
8
21 22 23 24
17
18
19
20
Binary input
floating
J
contact
Analog input
3 Electrical connection
1
Option 1:
Relay K4
16A/250V AC
or built-in alarm buzzer
P
S
Ö
10
11
12
Supply voltage
(L-) (L+)
12 — 24 V AC/DC +15/-15 %, 48 — 63Hz
J
Analog input 2 for Pt100, Pt1000, KTY1X-6 or KTY2X-6
1 for
Pt100, Pt1000, KTY1X-6 or KTY2X-6
8
