Contents
Introduction ...................................................................................................................................... 10
Use ................................................................................................................................................... 10
Hob cleaning and maintenance......................................................................................................... 10
Support ............................................................................................................................................. 11
Safety instructions............................................................................................................................. 11
Installation......................................................................................................................................... 12
Technical Data................................................................................................................................... 14

Introduction

Thank you for choosing a Franke product. Before using the appliance, please read all the instructions and advice
contained in this manual. In this way you will be able to make best use of the appliance and also ensure its lasting
efficiency. Keep this booklet for further reference.

Use

Lighting the burners
In these models lighting is done with the knobs. To light the burners, proceed as follows:
1. Press and turn the required knob.
2. Keep the knob pressed down for 3-4 seconds to allow the sparks to ignite the gas coming out the flame spreader and
to allow the thermocouple to heat up.
3. Then release the knob and, turning it anticlockwise (in models 604 and 1204, to the lighting symbol *), adjust the
flame as required. If the flame does not stay alight, repeat the operations from step 1.
Burner use
For lower gas consumption and better efficiency, it is advisable to use pots of widths suitable for the burners, making
sure the flame does not go beyond the edges (comply with the table on page 14).
Automatic safety valve
These hobs have a safety device that automatically closes the gas cock if the flame accidentally goes out due to draughts,
a pot spilling over, or a temporary interruption of the gas supply. This device is activated approx. 30 seconds after the
flame goes out.

Hob cleaning and maintenance

Before carrying out any hob cleaning or maintenance, always unplug the appliance or disconnect the power
by means of the main switch.
• Never use steam appliances, scouring pads, steel wool, muriatic acid or other products which could scratch or mark
the surface.
• Do not leave acid or alkaline substances on the hob.
• Never use sharp objects, as they could damage the seals between the trim and worktop.
• Do not use products containing sands, alkalis, acids, chlorides, oven sprays or detergents normally used to clean
dishwashers.
• To prevent scale deposits from forming, always thoroughly dry the appliance after going over it with a damp cloth.
• Immediately remove any foods with high sugar content that spill onto the hob.
• Remove grime with a damp cloth.
10
Symbols
: cock closed;
: lighting and max. delivery;
: min. delivery.
