1) GENERAL INFORMATION

The system has been studied to motorize sectional doors. To be applied onto balancing doors, a special fitting arm is required (item AU.C25).
Before proceeding with the installation check the following:
- the distance between the door highest point and the ceiling must be at least 40mm (fig. 2).
- it has to be possible to open and close the door by pulling and pushing horizontally its top edge (fig.2).
- manual moves must be smooth and regular.
The geared motor ROMEO can be coupled with the following rails:
Mod. Length
PTC.3 9B 3m
PTCI.3 9B 3m
Figure 1 reports the sizes.

Technical data

Power supply
Motor feed and Contol unit power supply
Absorbed rating
Accessories power supply
Drive speed
Drive/thrust force
Degree of protection
Jogging
Operating temp.
Noise level
Maximum door height
Radio receiver
Memory capacity
Power unit weight
2) INSTALLATION
2.1) WHOLE RAIL
In case of using a whole rail, go directly to point 2.3. Whole rails are provided with the belt already correctly tensioned.
2.2) TWO PIECE RAIL
a) Place the track on a flat surface and lay it as shown in Fig.3
b) Referring to Fig. 4, align both ends of the tracks and fit them with the two plates P, by using the eight M6X16 screws, the nuts D and the washers R.
c) Make sure that the belt is correctly tensioned, normally any intervention isn't needed. If necessary, it can be adjusted through nut D, as shown in Fig.5.
The correctly tensioned belt keeps its position along the entire track, without bending, but still resilient at a slight pressure by hand.
2.3) ENGINE AND TRACK ASSEMBLY
a) Move the drive carrier (Fig.6) until the pulley housing (ref. S of Fig. 7a) touches the motor shaft pin (ref. P of Fig. 7a)
b) Fix the track to the basis of the gear motor, as per Fig.7b. Fit the track to the basis of the gear motor, with the 4 D4,8x38 screws.
The track can be installed by turning it by 90° with respect to the gear motor base, as indicated in Figure 7b.
2.4) ENGINE MOUNTING
a) Fit the hooking bracket S to wall (Fig.8). Mark the two fitting points corresponding to the centre of the door.
Is available as an optional accessory, art. PTC.AR to be used in replacement of the mounting brackets supplied with the track (fig.16).
b) Position the fitting brackets to ceiling by means of the special housings in the track, near the gear motor (Fig.9) and fix them by means of screws M
and nuts D.
c) By using a ladder, hoist the gear motor, mark the fitting points of the brackets, drill the holes and fix the gear motor by means of screws and screw
anchors suited to the material.
d) temporarily fix the opening mechanical stoppers, at end of track, by using the screws K, as highlighted in Fig.10a.
The mechanical closing stop is optional and must be purchased separately. (Art. PTC.STOP)
At the end of the adjustment phase of the automatic system, the stoppers will be positioned more precisely and firmly fixed to the track between the
2 screws K, while drilling two holes, as indicated in Fig. 10b.
Note: while making the holes, take care not to drill the stoppers as well.
e) Connect the driving rod A to the drive slide T by means of the pin P1 and the locking clip B1. The rod movement should not be obstructed (Fig.11).
Fix the bracket S to the door so that, with closed door*, the rod A is in an almost vertical position. Shorten the drive rod A, if required.
Secure the bracket S to the dragging rod using the other pin P2 and the locking clip B2.
*In the event of heavy doors, it is recommended to use both upper and front holes.
f) Insert the cord in the release lever and in the knob. Make a knot as indicated in the detail of Fig.11.

3) ACCESSORIES (OPTIONAL)

CB.SW Emergency Battery Kit:
It permits the operation of the automatic system in the event of power failure.
The kit is composed of: battery charge card, 2 batteries at 12V, fitting bracket, screws and cables.
The batteries must be installed on the upper part of the gear motor basis, as per Fig.14.
To connect batteries, please refer to specific instructions.
Note: Once installed, the batteries protrude from the track upper profile by approx. 10mm.
Strap Max. door height
8mm 2.5m
8mm 2.5m
15 cycles/hour (50°C) | 45 cycles/hour (20°C)
N°pieces
2x1.5m
1x3m
ROMEO
230 Vac ± 10% 50/60Hz
24Vdc
1,0A
24Vdc 500mA max.
12 m/min
600N
IP40
-20°C/+50°C
<70dB (A)
2,5m
built in 433,92 MHz confgurabile
64 rolling-code
2,4 kg
Weight
EN
8,77 kg
6,75 kg
