CAUTION! THE AUTOSET PROCEDURE DESCRIBED BELOW IS MANDATORY!
During the AUTOSET phase, the control unit performs a number of opening and closing movements during which essential operating
parameters are set, including:
- Start- and end-of-run positions.
- Start of the slowdown phases.
- Torque values applied during panel movement.
- Recognition of the device connected to the PHOT input.
Procedure:
1) With the control unit connected to the mains, press and hold down the PU1 + PU2 keys until the 3 red LEDs light up cyclically.
2) The AUTOSET procedure starts, some opening and closing movements are commanded.
3) At the end of the procedure the panel stops in the open position and the LED lights remain steady for 5s to confirm AUTOSET
correctly carried out.
During the AUTOSET phase, a deceleration space different from the default space set by the control unit, can be set. Proceed as
follows:
1) Start-up an AUTOSET procedure.
2) The panel will start slowly opening and closing.
3) A CLOSING movement will then start at normal speed, during which the slowdown starting point can be selected using an
S.S. command (transmitter, S.S. input, PU1) keys when needed.
4) An OPENING movement will then start at normal speed, during which the slowdown starting point can be selected using an
S.S. command (transmitter, S.S. input, PU1) keys when needed.
ENG
GENERAL INFORMATIONS
The product shall not be used for purposes or in ways other than those for which the product is intended for and as described in this manual.
Incorrect uses can damage the product and cause injuries and damages.
The company shall not be deemed responsible for the non-compliance with a good manufacture technique of gates as well as for any de-
formation, which might occur during use. Keep this manual for further use.
INSTALLER GUIDE
This manual has been especially written to be use by qualified fitters. Installation must be carried out by qualified personnel (professional
installer, according to EN 12635), in compliance with Good Practice and current code. Make sure that the structure of the gate is suitable
for automation. The installer must supply all information on the automatic, manual and emergency operation of the automatic system and
supply the end user with instructions for use.
GENERAL WARNINGS
Packaging must be kept out of reach of children, as it can be hazardous. For disposal, packaging must be divided the various types of
waste (e.g. carton board, polystyrene) in compliance with regulations in force. Do not allow children to play with the fixed control devices of
the product. Keep the remote controls out of reach of children. This product is not to be used by persons (including children) with reduced
physical, sensory or mental capacity, or who are unfamiliar with such equipment, unless under the supervision of or following training by
persons responsible for their safety. Apply all safety devices (photocells, safety edges, etc.) required to keep the area free of impact, crush-
ing, dragging and shearing hazard. Bear in mind the standards and directives in force, Good Practice criteria, intended use, the installation
environment, the operating logic of the system and forces generated by the automated system. Installation must be carried out using safety
devices and controls that meet standards EN 12978 and EN 12453. Only use original accessories and spare parts, use of non-original spare
parts will cause the warranty planned to cover the products to become null and void. All the mechanical and electrical parts composing
automation must meet the requirements of the standards in force and outlined by CE marking.
ELECTRICAL SAFETY
An omnipolar switch/section switch with remote contact opening equal to, or higher than 3mm must be provided on the power supply mains.
Make sure that before wiring an adequate differential switch and an overcurrent protection is provided.
Pursuant to safety regulations in force, some types of installation require that the gate connection be earthed. During installation, maintenance
and repair, cut off power supply before accessing to live parts. Also disconnect buffer batteries, if any are connected. The electrical installation
and the operating logic must comply with the regulations in force. The leads fed with different voltages must be physically separate, or they
must be suitably insulated with additional insulation of at least 1 mm. The leads must be secured with an additional fixture near the terminals.
During installation, maintenance and repair, interrupt the power supply before opening the lid to access the electrical parts
Check all the connections again before switching on the power. The unused N.C. inputs must be bridged.
WARNING DECAL
Apply the warning decal supplied to the door
WASTE DISPOSAL
As indicated by the symbol shown, it is forbidden to dispose this product as normal urban waste as some parts might be harmful for en-
vironment and human health, if they are disposed of incorrectly. Therefore, the device should be disposed in special collection platforms
or given back to the reseller if a new and similar device is purchased. An incorrect disposal of the device will result in fines applied to the
user, as provided for by regulations in force.
Descriptions and figures in this manual are not binding. While leaving the essential characteristics of the product unchanged, the manufacturer reserves
the right to modify the same under the technical, design or commercial point of view without necessarily update this manual.
