DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1.
Sanding pad
2.
Switch
3.
Adaptor
4.
Clamp
5.
Dust extraction add-on
6.
Fixing screw with washer
* Dierences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Various working tips
2. Sanding paper (80#)
3. Dust extraction add-on with adaptor + clamp
4. Hexagonal key
SELECTION OF WORKING TOOL
Below table presents examples of use for various working tools.
Name
HCS blade for wood
Delta sanding pad
INSTALLATION AND REPLACEMENT OF SANDING PAPER
Sanding pad is equipped with hook-and-loop attachment system for quick and easy replacement of
sanding paper. Choose sanding paper with appropriate gradation depending on the processed material
and desired level of material removal. All types of sanding paper, abrasive cloths and polishing felt are
allowed.
Use only appropriate sanding paper with holes (perforated).
● Put the sanding paper close to the sanding pad (1).
●
Place the sanding paper so its holes (
●
Press the sanding paper against the sanding pad (
●
Make sure that the holes on the sanding paper and sanding pad fully match; it ensures optimal conditions
for dust extraction.
●
To remove sanding paper, lift edge of it on one side and pull (
- 2 pcs
- 5 pcs
- 1 set
- 1 pce

PREPARATION FOR OPERATION

Type of material
Wood, wood-based
materials, plastics
Wood, wood-based
materials, abrasive
materials
a) match with the holes on the sanding pad (1).
1).
11
Intended use
Dividing and plunge cutting
in corners
and hardly accessible
places, near surface
Sanding in hardly accessible
places and in corners on a
hard ground
g. A).
Example
Cut outs in furniture
boards, cutting cove
bases short, plunge
cutting for tting oor
panels
Removal of mortar and
glue for ceramic tiles,
sanding solid wood,
polishing
