Electronic Maintenance Display; Operation; Operating Area - Snapper SPX RIDING MOWER Manuel D'utilisation

M Choke
N Fuel Level Gauge (if equipped)
O Ground Speed Pedals
P Seat Adjustment Lever
Q Mower Lift Lever
R Height-of-Cut Switch
S
Transmission Release Lever
T Fuel Tank
U Brake Pedal

Electronic Maintenance Display

4
8
Note: When you start the unit, the Total Hours show on the
maintenance display. The total hours will set to 0 after 999.9.
Display Total Hours, Trip Hours, and Clock
1. Push MODE (A, Figure 4) for less than 1 second to show
the Trip Hours.
2. Push RESET (B) for more than 3 seconds to set the Trip
Hours to 0.
3. Push MODE for less than 1 second to show the Clock.
See Set the Clock section.
4. Push MODE for less than 1 second to show the Total
Hours.
Set the Clock
1. Push MODE (A, Figure 4) for more than 3 seconds. The
hours will flash on the display.
2. Push RESET to adjust the hours.
3. Push MODE for less than 1 second to save the setting.
The minutes will flash on the display.
4. Push RESET to adjust the minutes.
5. Push MODE for less than 1 second to save the setting.
Maintenance Display
OIL CHANGE - This message shows after 50 hours of
operation. After you change the oil and filter, push MODE two
times to show OIL HRS. Then, push and hold MODE for 3
seconds to set the timer to zero. The display will automatically
clear.
AIR FILTER CHECK - This message shows after 25 hours of
operation. After you clean or change the air filter, push MODE
three times to show AIR FILTER HRS. Then, push and hold
MODE for 3 seconds to set the timer to zero. The display will
automatically clear.
CHANGE BLADES - This message shows after 100 hours
of operation. After you change the blade, hold the RESET
button for more than 3 seconds to set the timer to zero. The
display will automatically clear.
LOW BATTERY - This message shows when a battery
voltage problem occurs. The display will automatically clear
after servicing of the battery.
Note: The LOW BATTERY message shows on the display
before all other messages. Do the servicing of the battery
first. Then, do a check for other maintenance messages.

Operation

Read the Operator Safety section before you operate this
machine. Make sure that you know the controls and how to
stop the unit.

Operating Area

1. Know the area where you plan to operate the mower.
2. Make sure that the area is free of unwanted material that
could be picked up by the blades and thrown.
