9. Install the cover and tighten the fasteners.
14

Push the Tractor By Hand

1. Disengage the Power-Take-Off (PTO) (E, Figure 3).
2. STOP the engine. See Stop the Engine.
3. Pull the transmission release lever (S, Figure 15). Then,
push the lever down to lock in position.
15
4. The rider can be pushed by hand.
18
WARNING
Towing the unit will cause transmission damage. Do not use
another vehicle to push or pull this unit. Do not actuate the
transmission release lever while the engine is ON.

Check the Spark Plugs

WARNING
Unintentional sparking can result in fire or electric shock.
Unintentional start-up can result in entanglement, traumatic
amputation, or laceration.
When you test for spark:
• Use an approved spark plug tester.
• DO NOT check for spark with the spark plug removed.
NOTICE Spark plugs have different heat ranges. It is
important that the correct spark plug is used, otherwise,
engine damage can occur. Replace the spark plug with the
same type or equivalent one.
Clean the Spark Plugs
Clean the spark plugs with a wire brush and sturdy knife. DO
NOT use abrasives.
Check the Spark Plug Gap
Use a spark plug feeler gauge (A, Figure 16) to check the
gap between the two electrodes. When the gap is correct, the
gauge will drag slightly as you pull it through the gap.
To adjust the spark plug gap, use a spark plug gauge and
gently bend the curved electrode. Make sure that you do not
touch the center electrode or the porcelain.
16
Install the Spark Plugs
Tighten the spark plug with your fingers, and then, tighten it
with a wrench as shown in Figure 17.
• 180 in-lbs (20 Nm), OR
• 1/2 turn when you install the original spark plug, OR
• 1/4 turn when you install a new spark plug.
