Roller brush Deck
1
3
5
Orbital Deck
• Press the orbital pad on the pad hold-
er.
Notice:
Make sure that the pad is placed evenly on the pad
holder.
Suction nozzle assembly
• Position the suction nozzle [A2] be-
low the suction nozzle holder [A1].
• Press the foot pedal [1] down until
B
1
the suction nozzle holder engages.
1
1
A
A
• Attach the suction hose [B1] to the
1
connector [B2].
A
2
A
2
B
2
Filling the fresh water tank
Caution:
2
Max. permissible water temperature 60 °C/140 °F.
- Diversey recommends using cold water, as hot water
will adjust to the ground temperature as soon as it
comes into contact with the ground. Thus there are no
advantages to using hot water.
• The machine must be switched off.
4
A
B
1
2
B
C
E
• Fill the fresh water tank with water.
Maximum filling level (page 25).
• Swivel the folding stand into the holder, tip the tank cover
back into its original position and press it down until it locks.
Fill fresh water tank with Aquastop filter (optional)
• Fill the fresh water tank with water.
• Put your hand into the opening be-
tween tank cover and tank and pull
the unlocking grip [A].
• Open the tank cover.
• Swivel the folding stand [B2] out of
the holder [B1] and place it into the
tank recess [C].
• Remove the dosage cup [D] and the
fresh water filter [E]
D
• Connect a water hose to the Aquas-
top filter.
31
