Keypad PC Error
16 Motor overload (I
OC6
a
overload)
50 Heat sink temperature
OH
a > +85 °C
− Heat sink temperature
OH
e
> +80 °C
53 PTC monitoring (TRIP)
OH3
a
(is displayed if C0119
= 1 or 4)
54 Controller
OH4
a
overtemperature
203 PTC monitoring
OH51
(is displayed if C0119
= 2 or 5)
− DC−bus overvoltage
OU
c
L
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Fault detection and elimination
Cause
2
x t Motor is thermally overloaded, for
instance, because of
impermissible continuous current
l
frequent or too long acceleration
l
processes
Ambient temperature too high
Heat sink very dirty
Impermissibly high currents or too
frequent and too long acceleration
Motor too hot because of excessive
currents or frequent and too long
accelerations
PTC not connected
Controller too hot inside
Motor too hot because of excessive
currents or frequent and too long
accelerations
PTC not connected
Mains voltage too high
Braking operation
Earth leakage on the motor side
EDK82EV113 DE/EN/FR 8.1
8
Fault messages
Remedy
Check drive selection
l
Check setting of C0120
l
Allow controller to cool and ensure better
ventilation
Clean heat sink
Check drive selection
l
Check load, if necessary, replace
l
defective bearings
Check drive selection
Connect PTC or switch off monitoring
l Reduce controller load
l Improve cooling
l Check fan in the controller
Check drive selection
Connect PTC or switch off monitoring
Check voltage supply
l Prolong deceleration times.
l Operation with external brake resistor:
– Check dimensioning, connection and
cable of the brake resistor.
– Increase the deceleration times
Check motor cable and motor for earth fault
(disconnect motor from inverter)
155
