Dismantling:
1. Undo the screws from the right interlinking block of
the fieldbus node and the left adjacent component
(e.g. end plate).
Note
Do not bend the electrical plug connectors on the inter-
linking blocks.
2. Carefully remove the interlinking block of the fieldbus
node from the adjacent components without tilting it.
Installation:
Note
When interlinking blocks are arranged in series:
Do not bend the electrical plug connectors on the inter-
linking blocks.
1. Align the CPX terminal on a flat surface so that the
components are not offset. The bolts attached to the
left-hand side of the interlinking block help you with
the alignment.
2. Push the interlinking blocks together carefully without
tilting them.
3. Screw the connector screws a few rotations into the
adjacent interlinking block.
4. Tighten the screws evenly, hexagon socket size A/F4,
tightening torque 3 Nm ± 0.3 Nm.
