Secure your wheelchair on uneven ground or when
•
transferring, e.g. into a car, by using the brakes.
If and whenever possible, during a journey in a specially
•
fitted vehicle for disabled people, vehicle occupants should
use the seats in the vehicle and the appropriate restraint
system. This is the only way to ensure that occupants will
have the maximum protection if there is an accident. When
using safety elements offered by SUNRISE MEDICAL and
using a specially designed safety system, lightweight
wheelchairs can be used as a seat when being transported
in a specially fitted vehicle. (See the Chapter on
"Transportation").
Depending on the diameter and setting of the castors, as
•
well as the centre of gravity setting of the wheelchair, the
castors may begin to wobble at high speeds. This can lead
to the castors being blocked and the wheelchair may tip
over. Therefore, please make sure that the castors are
adjusted correctly (see the Chapter "Castors"). In particular,
do not travel on an incline without brakes, travel at a
reduced speed. We recommend that novice users use anti-
tip tubes.
Anti-tip tubes should prevent the chair tipping over
•
backwards unintentionally. Under no circumstances should
they take the place of transit wheels, and be used to
transport a person in a wheelchair with the rear wheels
removed.
When reaching for objects (which are in front of, to the side
•
or behind the wheelchair) make sure that you do not lean
too far out of the wheelchair, as if you change the centre of
gravity there is a risk of tipping or rolling over. The hanging
of additional load (back pack or similar items) onto your
chair backposts can affect the rearward stability of your
chair, especially when used in combination with recliner
backrests. This can cause the chair to tip backwards
causing injury.
Adjustments to your wheelchair, particularly to safety-
•
related components must be carried out by an approved
dealer. This applies to adjustments to wheel locks, anti-tip
tubes, backrest angle and height, lower leg length, COG,
lap belt, rear wheel toe-in and camber, seat height as well
as toe-in and directional stability of the castor fork.
When using mobility accessories fitted to the wheelchair
•
such as handbikes, electronic power assist, etc, make sure
that your wheelchair is fitted with the appropriate castor
forks, approved for this use. Please contact your dealer if
you have any questions.
Do not fit any unauthorized electronic equipment, powered
•
or mechanically operated mobility drives, hand-bike or any
other device that changes the intended use or the structure
of the wheelchair.
Any combination with other medical devices requires the
•
approval of Sunrise Medical.
Please note that in certain configurations the wheelchair
•
may exceed a width of 700 mm. If this is the case, under
certain circumstances, it may not be possible to use some
or all of the available escape routes from a building. It may
be more difficult or impossible to travel on public transport.
For thigh amputees you must use anti-tip tubes.
•
Before setting off, check that your tyre pressure is correct.
•
For rear wheels it should be at least 3.5 bar (350 kPa). The
max. pressure is indicated on the tyre. The knee-lever
brakes will only work if there is sufficient tyre pressure and
if the correct setting has been made (see the Chapter on
"Brakes").
If the seat and back sling are damaged, you must replace
•
them immediately.
Be careful with fire, in particular with burning cigarettes.
•
Seat and back slings can be set alight.
If the wheelchair is subject to direct sunlight for a long
•
period of time, then parts of the wheelchair (e.g. frame,
legrests, brakes and sideguard) may become hot (>41°C).
Always make sure that the quick-release axles on the rear
•
wheels are set properly and lock in. If the button on the
quick-release axle is not pressed in, the rear wheel cannot
be removed.
8
WARNING!
The effect of the knee-lever brake as well as the general
•
driving characteristics are dependent on tyre pressure. The
wheelchair is significantly lighter and easier to manoeuvre
when the rear wheels are pumped up correctly and both
wheels have the same pressure.
Make sure that your tyres have sufficient tread! Please note
•
that you are subject to any and all traffic laws when driving
in public traffic.
Always be careful with your fingers when working or
•
adjusting the wheelchair!
WARNING!
CHOKING HAZARD – This mobility aid uses small parts which
under certain circumstances may present a choking hazard to
small children.
The wheelchairs shown and described in this user guide may
not correspond in every detail exactly to your own model.
However, all instructions are completely relevant, regardless of
possible detail differences.
The manufacturer reserves the right to alter without notice any
weights, measurements or other technical data shown in this
manual. All figures, measurements and capacities shown in this
manual are approximate and do not constitute specifications.
Sunrise Medical is ISO 9001 certified, and this guarantees
quality assurance in the development and production processes
of all our products. This product complies with the standards set
forth in EU directives. Optional equipment and accessories are
available at extra charge.
