Operating Instructions:
Dehumidifying is a means of removing moisture from the
air.that will help to protect your home and valued
possessions from damage (swelling) caused by moisture
in the air. It also prevents mold and mildew from
accumulating in damp areas of the home. Essentially a
dehumidifier removes moisture from the air, as moist air
passes over a dehumidifying (evaporator cooling) coil.
Moisture is condensed on the evaporator coil, drained
and collected inside an internal (removable) water tank
located at the front of the unit. The exhausted air being
returned into the room environment is elevated several
degrees causing the surrounding air temperature to
increase (slightly). This process contributes to lowering
the relative humidity of the surrounding air.
Factory Default Setting:
When the unit is first connected to a power supply, the
electronic circuit board will automatically default to the
following factory settings.
Mode: Dehumidifier
Humidity Set Air Value:60% RH
Fan Speed: = Low
NOTE:In the event of a power failure or the unit is
switched 'Off', the most recent settings are retained and
restored once the power is switched "On"/resumed.
IMPORTANT NOTE: Depending on humidity conditions,
(when power is restored or switched 'On') the
dehumidifier may not start automatically under the factory
or custom ( see page 7 ) default setting . This is an
indication the RH% level of the surrounding environment
is lower than the current default setting and it may be
necessary to select a lower SET AIR (RH%) value.
DEHUMIDIFYING MODE SELECTION:
1. The unit does not have to be switched on
(operational) to select/set a program. All programs can be
selected with the unit in the "off" position
2. Press the MODE button and select dehumidifier mode
(a rain drop symbol will appear in the display). Each time
the button is pressed, the setting will alternate between
DRY (dehumidifier) mode and FAN (only) mode.
3. Press the "UP" or "DOWN" buttons to select the desired
SET AIR operating value. (between 35% ~ 80%) To
select CONTINUOUS dehumidifying mode, press the
DOWN button until the symbol "- -" appear in the SET
AIR display. NOTE: During CONTINUOUS mode
operation, the humidistat (control) will be by-passed and
the compressor will operate non-stop regardless of
humidity conditions.
All manuals and user guides at all-guides.com
Operating Instructions
FAN SPEED SELECTION:
4. Press the fan symbol on the keypad. Each time the
button is pressed, the mode selection will alternate
between "High Fan" and "Low Fan" speed options. The
fan speed you select will appear in the LED display;
either a 5 blade fan symbol for 'high fan' or a 3 blade fan
symbol for 'low fan' will be shown in the display area.
5. When all settings are complete, press the I/O button to
start dehumidifier operation and the blue operation light
will illuminate.
FAN MODE SLECTION:
1. The unit does not have to be switched on
(operational) to select/set a program. All programs can be
selected with the unit in the "off" position
2. Press the MODE.button and select fan mode (fan blade
symbol will show in display). Each time the button is
pressed, the setting will alternate between dehumidifier
mode and fan (only) mode.
3. Press the "Fan" symbol on the keypad. Each time the
button is pressed, the mode selection will alternate
between "High Fan" and "Low Fan" speed options.
4. When all settings are complete, press the on/off button
to start fan mode operation and the blue operation light
will illuminate.
AIR FILTER:
Your dehumidifier features a removable Air Filter. This
filter is located at the front of the unit (behind the front air
intake grill) The air filter plays an important role in helping
to reduce (minimize) dust/dirt particles from the
surrounding environment. A blocked/clogged air filter
reduces air flow impacting negatively on operating
efficiency. To maintain maximum operating efficiency; The
filter must
be checked and cleaned regularly. (every 2 weeks) More
frequent cleaning may be required depending upon
indoor air quality.
IMPORTANT: Never operate the unit without the air
filter in place.
AIR FILTER REMOVAL:
1. Locate the air filter (handle) tab on the upper right side
2. Clean the filter thoroughly using a vacuum cleaner or
3. To re-install the air filter, slide the filter back inside
10
of the front air intake grill and slide-out the filter to
the right.
wash using luke warm water and mild detergent.
Dry thoroughly before re-installing.
the tracks until it snaps (locks) into position.
