Installation and Operating Instructions
UK
CHAPTER 3
TECHINCAL DATA
Centrifugal in-line fans – InlineVent
3.0
InlineVent RR.. type overview
Ø A
Ø B
243
99
RR 100 A
243
99
RR 100 C
243
124
RR 125 C
271
159
RR 160 B
345
159
RR 160 C
345
199
RR 200 A
345
199
RR 200 B
345
249
RR 250 A
345
249
RR 250 C
402
314
RR 315
3.1
Type plate
Example:
e
y
o
d
Key for fan type plate:
– Manufacturer's address
— Fan label:
CE = CE mark
˜ Version:
RR
= type designation
315
= Size
™ Item number
š Production code / year of manuf.
The fan can be clearly identified by the ref. no., SNR (serial number) and PC (production code) numbers.
3.1.1 Motor type plate
Technical data about the motor can be found on the motor type plate!
RR..
®
Dimensions in mm
C
D
E
F
136
188
26
26
136
188
26
26
134
188
27
27
133
195
30
32
164
226
30
32
160
228
33
35
160
228
33
35
160
228
33
35
160
228
33
35
185
257
32
40
q
r
t
u
i
s
f
› Nominal voltage / Frequency
œ Current in rated operation / Current in reg. operation
Total input power
ž Nominal speed / Motor insulation class
Ÿ max. flow medium temp. at rated / regular operation
s Cosine
d Capacitor / protection class
f Installation and operating instructions/ Print no.
4
InlineVent – centrifugal in-line fans
Series
RR 100 A
Ref. no. 5653
RR 100 C
Ref. no. 5654
RR 125 C
Ref. no. 5655
RR 160 B
Ref. no. 5656
RR 160 C
Ref. no. 5657
RR 200 A
Ref. no. 5658
RR 200 B
Ref. no. 5659
RR 250 A
Ref. no. 5652
RR 250 C
Ref. no. 5660
RR 315
Ref. no. 5920
Energy-efficient, backward curved, high-
performance centrifugal plastic impeller
(Type RR 315: galvanised sheet steel)
Fig.1
w
