Figure 3.4: OSCAR Interface Name Modify Dialog Box

2. Type a name in the New Name box. Names of target devices may contain all printable characters.
3. Click OK to transfer the new name to the Names dialog box. Your selection is not saved until
you click OK in the Names dialog box.
4. Repeat steps 1-3 for each target device in the system.
5. Click OK in the Names dialog box to save your changes.
-or-
Click X or press
Escape
NOTE: If an AVRIQ module has not been assigned a name, the EID is used as the default name.
To list target devices alphabetically by name:
Press or click Name in the Main dialog box.
Alt+N
To access the OSCAR interface Devices dialog box:
1. If the OSCAR interface is not open, press
2. Click Setup - Devices to open the Devices dialog box as shown in Figure 3.5.
NOTE: The Modify button is available only if a configurable switch is selected.
to exit the dialog box without saving changes.
Print Screen
Chapter 3: Local Port Operation
to open the Main dialog box.
19
