Error messages when assembly is wrong
Error Description
code
E - 3 Temperature sensors were mixed up during installation or
connection.
E - 6 Meter were installed against the planned flow direction.
During system downtime the error messages "E - 3" and "E - 6"
may appear without possible wrong assembly inside.
4.

Communication

4.1 M-Bus wired (optional)

A 2 pin M-Bus line lead out of the housing.
Connect the M-Bus line with the marked connections of the
M-Bus Master.
Here it concerns a serial interface for communication with external devices
(M-Bus control centres), e.g. IZAR CENTER.
ƒ
Standardised according to EN 13757-3
ƒ
Galvanic isolation
ƒ
Polarity reversal protection
ƒ
Power consumption: One M-Bus load
ƒ
Primary or secondary addressing
ƒ
Baud rate 300 or 2400 baud (automatic baud rate detection)
ƒ
Protocol: M-Bus
ƒ
Reading interval: every 3 minutes *
* the meter detects, if the reading is done more often than every 3 min-
utes. The meter refuses and shows in the display as well as in the header
of the M-Bus telegram the error code E - 5 (frequent reading via M-Bus).
