This appliance is not intended for use by person (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

PARTS NAME

Fresh air Intake unit
MMD-AP0481HFE, MMD-AP0721HFE, MMD-AP0961HFE
Air supply port
Cools/heats the fresh air and
sends it into the room with the
air supply flange.
Blow temp. sensor
Drain pan
All manuals and user guides at all-guides.com
3
Air intake port
Intakes the fresh air
with the inlet flange.
Earth screw
It is included in the electric parts box.
