Compound mitre saw
SYMMETRIC SYM 70
Table of contents
1 Technical data
2 Graphical symbols
3 Intended use
4 Safety instructions
5 Machine elements
6 Settings
7 Power supply and start-up
8 Operation
9 Service and maintenance
10 Accessories
11 Disposal
12 Warranty
1 Technical data
Power
Rotational speed (idle)
Mitre angle
Inner angle
Outer angle
Cutting range
max. workpiece height
max. workpiece width
Saw blade
Weight
Protection class
The specifi ed illustrations are at the beginning of
the Operating Instructions.
2 Graphical symbols
Caution. Danger!
Read the operating instructions/notes
Wear ear protection!
3 Intended use
The electric power tool is a stationary unit de-
signed for sawing blocks of wood, plastic or
aluminium.
Other materials, in particular steel, concrete and
mineral materials, must not be processed.
Aluminium must only be sawed with the special
saw blades from Festool designed for this pur-
pose.
All manuals and user guides at all-guides.com
1150 W
2700 - 5200 rpm
0° - 68°
0° - 60°
70 mm
80 mm
216 x 2.4 x 30 mm
9.6 kg
/ II
13
The electric power tool is designed and approved
for use by trained persons or specialists only.
The user bears the responsibility for dam-
age and accidents caused by improper
use.
Other risks
In spite of compliance with all relevant
design regulations, dangers may still
present themselves when the machine
is operated, e.g.:
• Workpiece parts being thrown off
• Parts of damaged tools being thrown off
• Noise emission
• Sawdust emission
4 Safety instructions
4.1 General safety instructions
WARNING! Read all safety warnings and
all instructions. Failure to follow the warn-
ings and instructions may result in electric shock,
fi re and/or serious injury.
Save all warnings and instructions for future
reference.
The term „power tool" in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
• Never allow children to use the machine.
• Before using the machine, make yourself suf-
fi ciently familiar with the application, setting and
operation of the machine.
4.2 Machine-related safety instructions
Safety precautions
• Always use original Festool tools (in accordance
with EN 847-1).
• Use only correctly sharpened tools without dam-
age or deformation. The maximum rotational
speed specifi ed on the tool must be observed.
• Select the saw blade suitable for the material
you wish to work on.
• Do not use saw blades made of high-speed
steel.
• Only use spacers and spindle rings specifi ed by
Festool.
• Ensure the work area has adequate lighting.
• Ensure that the machine is on a firm base.
Place the machine on a fl at fl oor or secure the
machine fi rmly on a bench or table.
• Only use the machine if all protection devices
are in their correct positions, the machine is in
good condition and has been well maintained.
