Getting Started
Connecting the Speakers
After connecting the front, center and rear speakers, and/or a
subwoofer, set the speaker setting information properly to obtain the
best possible Surround effect. For details, see page 20.
CAUTIONS:
• Use speakers with the SPEAKER IMPEDANCE indicated by the
speaker terminals (8 – 16 Ω).
• DO NOT connect more than one speaker to one speaker terminal.
Connecting the front, center, and rear speakers
1
For each speaker, connect the (+) and (–) terminals on the rear panel
to the (+) and (–) terminals marked on the speakers respectively.
1 Cut, twist and remove the insulation at the end of
each speaker cord (not supplied).
2 Press and hold the clamp of the speaker terminal
(1), then insert the speaker cord (2).
3 Release the clamp.
FRONT
SPEAKERS
CAUTION:
SPEAKER
IMPEDANCE
8
16
To right front
speaker
To left front speaker
RIGHT
FRONT
SPEAKERS
CAUTION:
SPEAKER
IMPEDANCE
8
16
AV COMPU LINK-
2
3
1
2
RIGHT
LEFT
RIGHT
LEFT
CENTER
REAR
SPEAKER
SPEAKERS
To right rear
speaker
To center speaker
LEFT
RIGHT
LEFT
CENTER
REAR
SUB-
SPEAKER
SPEAKERS
WOOFER
DIGITAL 1
OUT
(DBS)
DBS
VCR
OUT
IN
IN
(REC)
(PLAY)
AUDIO
TV
TAPE / CDR
DBS
VCR
S-VIDEO
LEFT
RIGHT
IN
OUT
IN
IN
OUT
IN
Y
P
P
B
R
(REC)
(PLAY)
(REC)
(PLAY)
DVD COMPONENT VIDEO OUT
Connecting the subwoofer speaker
By connecting a subwoofer, you can enhance the bass or reproduce
the original LFE signals recorded in the digital software.
CAUTION:
SPEAKER
IMPEDANCE
8
Connect the input jack of a powered subwoofer to the SUB-
WOOFER OUT jack on the rear panel, using a cable with RCA pin
plugs (not supplied).
• Refer also to the manual supplied with your subwoofer.
Note:
• You can place a subwoofer wherever you like since bass sound is
non-directional. Normally place it in front of you.
SUB-
WOOFER
OUT
To left rear
speaker
To obtain the best possible sound from this system, place all the
speakers except the subwoofer at the same distance from the
DIGITAL IN
DIGITAL OUT
DIGITAL 2
listening position with each speaker's front faced toward the
(TV)
PCM/STREAM
MONITOR
MONITOR
DBS
VCR
listener.
OUT
IN
OUT
OUT
IN
(REC)
(PLAY)
Then, change the subwoofer and speaker settings to fit your
VIDEO
AM LOOP
listening conditions (see page 20).
FM 75
COAXIAL
AM EXT
ANTENNA
RIGHT
LEFT
RIGHT
LEFT
FRONT
CENTER
SPEAKERS
SPEAKER
16
Powered subwoofer
(example)
Speaker Layout Diagram
Center speaker
Left front
Right front
speaker
speaker
Left rear
Right rear
speaker
speaker
REAR
SUB-
SPEAKERS
WOOFER
OUT
Subwoofer
6
