3. Remove the frothing tube (6c).
6c
4. Clean the individual parts with a
detergent solution and a soft brush. If
necessary, soak in a warm detergent
solution. Clean the air hole (6e)
thoroughly.
5. Rinse all parts with clean water and dry.
6. Fit the steam nozzle (6d) and frothing
tube (6c) back into the metal sleeve.
6c
1
7. Twist the steam nozzle clockwise until
the marks are aligned.
8. Attach the milk frother to the steam
valve. Check that the red mark on the
steam valve is covered.
All manuals and user guides at all-guides.com
¡
Only use the appliance when the milk
frother (6) is completely assembled and
fitted.
Cleaning the brewing unit
Clean the brewing unit regularly.
To pre-clean the brewing unit automatically:
1. Select
2. Place an empty glass under outlet (7).
3. Press the start button (10).
6e
The appliance rinses.
In addition to the automatic cleaning pro-
gramme, the brewing unit (5a) should be
removed regularly for cleaning. (See figure
E at the start of the operating instructions.)
1. Switch the appliance off at the power
2. Open the door (5b) to the brewing unit.
3. Slide the red lock (5d) on the brewing
4. Press the eject lever (5c) down fully. The
6d
5. Grasp the brewing unit (5a) by the
2
6. Remove the cover (5e) of the brewing
Risk of scalding!
e
by turning the rotary knob (14).
on/off switch O / I (9). No buttons are lit.
unit (5a) completely to the left.
brewing unit is released.
recessed grips and remove carefully.
unit and rinse the brewing unit (5a) thor-
oughly under running water.
