Installing the Antenna Panel
The TWR-5 has an internal reader, that when connected to a Gallagher Antenna
panel will capture the Electronic ID tag data.
To weigh animals in a crush, you will need:
• Gallagher Antenna Panel kit
• 4m Antenna Extension Cable G05600 or
6m Antenna Extension Cable G05602
Note: A short adapter cable G05601 may be required on early versions of the
Sheep Auto Dra er made prior to 2018.
To mount your Antenna panel, refer to the instruc ons included with the panel.
Important: Use the defi ned moun ng holes, because drilling through the
Antenna Panel will damage the antenna.
Attaching the TWR-5 to the Antenna Panel
1. Ensure the TWR-5 is turned OFF.
2. On the Antenna Panel, unscrew the Amphenol connector locking nut from the
Amphenol socket and pull it down to unplug from the Antenna Panel.
Moun ng bracket
Moun ng holes
Antenna Cable
Moun ng holes
3. Connect the extension cable to the Amphenol connector and ghten, then
connect the other end of the extension cable to the Antenna connector on
the base of the TWR-5.
4. Tighten the locking nut.
5. Refer to Connec ng Equipment to the TWR-5 (p. 8) to complete the EID
Reader connec on on the TWR-5.
6
Gallagher TWR- Weigh Scale Quick Start Guide
Amphenol connector
Amphenol connector (2.)
Moun ng holes
Moun ng holes
