Commande et paramétrage
****RÉSEAU IT****
R >010 MΩ
- EDS: off -- auto --
******************
Menu
item
8 ... 11
HISTORY INFO
ISO SETUP
Nr.: 01
#Nr.: 02
Power on
12.09.02 09:21
Clear all: off
1. EXIT
2. Alarm1 040 kΩ
3. Alarm2 010 kΩ
4. K1 : NO
5. K2 : NO
6. Memory: off
7. M+/M-: 0-20 mA
IRDH575_D00089_00_M_XXFR/06.2014
MENU
1. EXIT
2. HISTORY INFO
3. ISO SETUP
4. ISO ADVANCED
5. EDS SETUP
ESC
6. EDS 460/490
7. EDS 470
8. COM SETUP
9. PASSWORD
10. LANGUAGE
11. SERVICE
ESC
ISO ADVANCED
EDS SETUP
1. EXIT
2. AGH : no
3. Ce max: 150 μF
4. Measure: AMP
5. Autotest: 24h
6. Clock: 19:08
7. Date: 01.01.01
8. Test:
12:00
1. EXIT
2. EDS: auto
3. System: 3AC
4. MaxPuls:025mA
5. K3 Alarm: on
EDS 460/490
1. EXIT
2. General
3. Channel
4. Relay: N.O
5. Test/Reset
EDS 470
1. EXIT
2. EDS-Monitor
3. EDS Test: off
4. EDS Reset: off
5. Relay: N.O
6. Memory: on
7. CT Setup
8. n-peak: 001
35
