RF Rx SW868/SW915/SW917/SW922-4S
//
Montage- und Anschlussanleitung / Funkempfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur sans fil
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor sem fio
Инструкция по монтажу и подключению / Радио-приемник
English
Use of the mounting and wiring instructions
Target group: authorised and qualified staff.
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer.
In case of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
1 device, 1 mounting and wiring instructions, carton.
Intended use
The four channel wireless receiver is used to switch electrical loads via
radio transmission. The transmitters must conform to the steute
sWave ® protocol of the LR and ULR modules. The output of the receiv-
er can be switched by a maximum of 40 transmitters. Therefore, each
transmitter must be taught in once.
Option status memory
After power-on with the receivers with status memory
RF Rx SW868/ 915/917/922-4S-S, the last valid status of the outputs
is re-established.
Mounting and wiring
The wireless range depends heavily on the local conditions. Conductive
materials may strongly affect the radio signal. This also includes thin
foils, e.g. aluminium laminations on insulation materials.
Antenna
Use suitable antennas only:
Device Antenna
SW868/922 Antenna with cable and SMA
plug-in connector
SW915/917 Antenna with cable and SMA
plug-in connector
Mount the antenna on a metal plate. The metal plate serves as an
HF counterweight. Minimum size of metal plate: 250 x 250 mm. Note
minimum sideways distance to nearest wall or disturbance source:
>300 mm. Do not bend or clamp the cable. Minimum bending range of
cable: >25 mm.
Material No.
1373201
1373187
Assignment of the place of use:
Device type
SW868
SW915
SW917
SW922
Assignment of radio frequency:
Device type
SW868
SW915
SW917
SW922
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Material No.
1188958 Place of use
in free field (SW868/915/917 LR)
1188987
in free field (SW868/915/917 ULR)
in free field (SW922 LR)
in free field (SW922 ULR)
indoors (SW868/915/917 LR)
indoors (SW868/915/917 ULR)
indoors (SW922 LR)
indoors (SW922 ULR)
4 / 28
Receiver SET incl. stick-on antenna
RF Rx SW868 4S 24VDC (SET)
RF Rx SW915 4S 24VDC (SET)
Place of use according to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Radio frequency
868.3 MHz
915.0 MHz
917.0 MHz
916.5 MHz
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
700 m
150 m
230 m
40 m
50 m
20 m
25 m
