Technical data

3.4.1

Performance data

General
Max. operating
temperature
Min. operating
temperature
Max. operating
pressure
Control range
Control range
Δp max.
Δp min.
(0.5 - 2 l/min)
Δp min.
(>2 - 2.8 l/min)
Δp min.
(>2.8 - 5 l/min)
Below Δp min. a normal thermostatic
valve function is given, i.e. the set flow
value is undercut depending on the
differential pressure.
3.4.2

Data for actuator connection

Connection thread
Valve stroke
Closing dimension
Closing force
(actuator)
140495282-V01.09.2021
+60° C
+2 °C
6 bar (600 kPa)
0.5-5 l/min
150 kPa (1.5 bar)
10 kPa (0.10 bar)
15 kPa (0.15 bar)
20 kPa (0.20 bar)
M30 x 1.5
1.8 mm
11.8 mm
90 - 150 N
3.4.3

Dimensions

SW37
G3/4
50
Fig. 6: Dimensions
Item no. Circuits
1404952 2
1404953 3
1404954 4
1404955 5
1404956 6
1404957 7
1404958 8
1404959 9
1404960 10
1404961 11
1404962 12
4. Accessories and spare parts
The product is supplied with extensive
accessories (see par. 1.2 on page 17). Ball
valves and heat meters are not included in the
scope of delivery.
32,5
52.5
L max. 75
Length (L)
188 mm
238 mm
288 mm
338 mm
388 mm
438 mm
488 mm
538 mm
588 mm
638 mm
688 mm
21
