Quiet Oil-Free Air Compressor

ELECTRICAL POWER

Electrical Power Requirements
There is a danger of electric shock.
Use only undamaged electrical cords.
DO NOT touch bare wires or receptacles.
DO NOT operate air compressor in wet weather or in
wet conditions.
DO NOT touch air compressor or cords if hands or feet
are wet.
Ensure that all cords are free of damage before
connecting to the power supply.
Ensure that you have a sufficient electrical supply for
supporting the requirements of the motor.
Improper installation of the grounding plug is able
to result in a risk of electrical shock. When repair or
replacement of the cord or plug is required, do not
connect the grounding wires to either flat terminal. The
wire with insulation having an outer surface that is green
with or without yellow stripes is the grounding wire.
This product must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electrical shock by providing an escape wire for the
electrical current.
This product is equipped with a cord having a grounding
wire with an appropriate grounding plug. The plug
must be plugged into an outlet that is properly installed
and grounded in accordance with local codes and
ordinances.
This product is for use on a nominal 120-V circuit and
has a grounding plug similar to the plug illustrated in
sketch A. Only connect the product to an outlet having
the same configuration as the plug.
Do not use an adapter with this product.
Before using the air compressor, refer to the Compressor
Rating Label for voltage and amperage requirements. Make
sure you have a sufficient electrical supply for supporting
the motor's requirements.
Use a dedicated 15 amp circuit for best results. Low voltage
and/or an overloaded circuit can cause the motor's overload
protection to trip.
10
Customer Support 503-253-7308 M-F, 8am-4:30pm PST | iwata.support@iwata-medea.com | www.iwata-airbrush.com/blog/contact-us
Electrical Extension Cords
Use caution when using extension cords.
Use an extension cord which is no more than 27' (7.6 m)
long and at least 14 gauge.
Using an excessively long or thin-wired extension cord
will cause severe damage to the motor.
Use only a 3-wire extension cord that has a 3-blade
grounding plug.
As undersized cord results in a drop in the line voltage
and loss of power and overheating.
When in doubt, use a heavier gauge. The smaller the
gauge the more current the cord can carry.
Inspect all electrical extension cords to ensure that they are
free of damage.
When using an extension cord, use a heavy-duty cord that is
no more than 25 feet long and at least 14 gauge. Use only a
3-wire extension cord that has a 3-blade grounding plug.

OPERATING THE AIR COMPRESSOR

This manual contains important instructions for
operating this product. For your safety, and the safety
of others, be sure to read this manual thoroughly before
operating the product.
Failure to properly follow all the instructions and
precautions can cause you and others to be seriously
hurt or killed.
Save this manual for future reference.

Introduction

This air compressor features a compact structure, stable
performance, a high airflow rate, easy operation and main-
tenance. because the air compressor produces no oil in the
airflow, it can be used as an independent air supply machine
for situations in which oil in the airflow is an issue. The motor
directly drives the pistons and is able to function without
lubrication for a long period of time.

Assembly

1. Connect your air supply hose to a 1/4" male universal or
industrial quick connect coupler. Connect the male quick
connect coupler to the female quick connect coupler locat-
ed on the air compressor.
2. Make sure the drainage valve is off and that the pressure
switch is in the OFF position.
3. ensure that the power supply you are going to use is oper-
ating normally.
4. Insert the power supply cord into the power supply socket.
www.iwata-airbrush.com
